ALL SKY special projects

Ordering information :

• Please contact us for information and pricing concerning this camera.

Software
Either our custom made Alcor System software or
SDK can be provided so that any custom algorithm can be implemented by the end user.

Parameter	Value
Field of view	Filed of view is 100° x 70 ° (OMEA 7C) Image scale is 1.3 arcmin/pixel Factory focused and tilt tuned with respect to the whole image sensor field.
Camera resolution	4150 x 2800 3.8 µm pixel size (Rolling shutter) All monochrome or color, progressive scan, anti-blooming sensor.
ADC resolution	14 bits
Video stream	ALL Cameras have video stream capabilities AVI file stream can be created 2.5 fps USB 2.0 - 15 fps USB 3.0 e is disabled for cooled camera !
Exposure time	From 32µs to one hour exposure (All-Sky mode, typically 20s to 75s)
Gain	Variable, 4 e-/ADU down to 0.02 e-/ADU
Dome	BK7 Glass Dome
Image download time	200ms Max
Auto-iris	Embedded
Remote re-focusing	Embedded
Image Sensor Cooling	Sensor Cooling is 20°C from ambiant
Control software	ALCOR SYSTEM's All Sky software supplied at no additionnal costs.
Operating system	Windows 32&64 bits (Seven and 10) Linux (contact us) SDK available
To PC interface	USB 2.0 + 20 m length cable, perfectly full time reliable operation. Ethernet link on request.
Top dome heater	Automatic dome defrost based on provided external temperature and humidity sensors. User tunable heating power from 18W to 36W
Power supply	24V / 3A (Power supply provided)
Other informations	Enduring bad weather condtions (rain/snow), anodized aluminium casing, glass dome, water tight connectors and body / IP67 protection Special Mechanical stand is mandatory
Weight	4.5 kg
Dimensions	Ø130mm x 270 mm
Operating temperature range	from -35°C to +45°C

The purpose of these systems is to carry out All or Full Sky surveillance of the night or day sky, and in a continuous fashion. It is possible to assess, in real time, the night sky quality, and to record fast phenomena (meteors and fireballs) or slower (satellites, rockets, noctilucent clouds, zodiacal light, aurora, airglow ....).

Thanks to its high sensitivity, this system can record a very good image quality of the night sky, while producing images of stars that will not be trailed by natural Earth rotation, no star tracking is required.

This camera is a special product, that has been purchased by 4 units. The aim of this project is to cover full horizon line in high resolution fashion with 4 camera laid 90° each other. The field of view of each camera is 100° horizontal by 70° vertical. A special stand has been design to include a bit of horizon line in the image. The camera is similar to OMEA 8 with a different lens.

Focus and auto-iris remote control are included.

Do not hesitate to contact us for more information

OMEA 7C image sample, click on the image to get full resolution image, and click again to get stretched image.
When recorded moon was 15% illuminated and camera aiming north, the light dome on the right of the image is
due to LYON city located at 70 km

OMEA 7C image sample, click on the image to get full resolution image, and click again to get stretched image.
Day time image
